Evolis Avansia Duplex Retransfer Card Printer

Evolis Avansia Retransfer Card Printer offers high-volume plastic card printing - ideal for producing over 20,000 cards per year. Evolis Avansia produces double-sided high-security ID badges and cards printed at a superior 600 dpi resolution. With standard USB and Ethernet connectivity and optional Magnetic Encoder, this Evolis retransfer printer offers the power and flexibility needed to produce the highest-quality, longest-lasting and tamper-resistant ID cards in-house.

Evolis Avansia is a retransfer card printer that offers very high quality plastic card production. Designed for rigorous use, Avansia is extremely robust and provides high security card issuance. It is ideal for organizations that need to produce the highest quality personalized plastic ID cards in medium and large quantities. Avansia is ideal for creating:

• Call for the lowest price on Evolis Printers
• Corporate ID cards
• Secure access badges
• Student cards
• Payment cards
• Loyalty cards / gift cards
• National ID cards
• Driver’s licenses

Key features

• Exceptionally fast output prints up to 140 single-sided color cards per hour
• High resolution 600 dpi – double the print quality of most card printers on the market – creates crisp, high-definition images, micro text and watermarks
• Avansia produces true over-the-edge card prints, guaranteeing that your edges print perfectly since the film fully covers the card
• 3-Year standard warranty and life time warranty on the print head
• Prints on all types of cards including uneven card surfaces, such as smart contact and contactless cards – standard dye sublimation for PVC cards and retransfer for ABS, Polycarbonate (PC) and most of the PET cards
• Configure and combine all types of data encoding options: magnetic stripe, and contact & contactless smart cards – Please contact us for Smart Card encoding options
• High capacity card hoppers (250 cards), print ribbons and transfer film produce cards with no interruption, even in critical environments (dust, heat...)
• High capacity printer ribbons and transfer films
• Secure print environment with an easy-to-use RFID electronic key that prevents any attempt to use the printer.
• Standard built-in card flattener delivers perfect results.

Full card:
Single side (YMCK): 25 s/card - 144 cards/hour
Dual side (YMCKK): 37.5 s/card - 96 cards/hour

Available modules:

• Magnetic stripe encoder ISO 7811

• Dual contact and contacless encoder

• Encoder connectivity: internal USB hub, 1 port available

• Encoding options can be combined

• Factory installed or installed on site for contact and contactless encoders

• USB (1.0, 1.1, 2.0, 3.0), cable supplied

• Ethernet TCP-IP 10BaseT, 100BaseT (Traffic Led)

• RFID locking key

• Support for security lock (Kensington® type)

• Centralized locking system to secure access to blank cards, ribbon and film (optional)2

• IPSec encrypted networking security

• Card feeder: 250 cards (0.76 mm – 30 mil)

• Card output hopper: 250 cards (0.76 mm – 30 mil)

• Reject tray capacity: 30 cards (0.76 mm – 30 mil)3

• Card thickness: 0.76 mm (30 mil), manual adjustment

• Card types:

                PVC cards
                Composite PVC cards
                PET-F cards
                PET-G cards
                Polycarbonate cards (PC)
                ABS cards

• Card format: ISO CR80 - ISO 7810 (53.98 x 85.60 mm – 3.370” x 2.125”)

Evolis High Trust® Ribbons

To maximize the quality and durability of printed cards, the lifespan of the print head and the overall printer reliability, use Evolis High Trust® ribbons.

• Ribbon capacity:
• Clear transfer film: 500 prints/roll
• Holographic transfer film: 400 prints/roll
• YMCK: 500 prints/roll
• YMCKK: 400 prints/roll
• YMCKI ribbon (for smart cards, magnetic stripes and signature panels): 400 prints/roll
• YMCKH ribbon (for non PVC cards): 400 prints/roll
• YMCFK ribbon (F = UV ink): 400 prints/roll

Software

• Compatible with Windows (32/64 bits): XP SP3, Vista,W7, W8, W10
• Delivered with cardPresso XXS for designing and editing badges

Display

• Two-line LCD display and LED status indicator
• Printer graphical notifications: empty input hopper, empty/low level ribbon alert...

Certifications and statement of compliance

• RoHS
• CE, FCC, UL, IEC

Size and weight

• Dimensions (H x W x D): 436 x 340 x 297 mm (17.16” x 13.38” x 11.69”)
• Weight: 20 kg (44.09 lbs)

Warranty

• 3 years for printer, lifetime warranty on print head
